Yarn Tension Dynamics and Closed Loop Control (Engineering) Quiz, Textile

Question 1

What is the primary operational function of a closed-loop control system in yarn tension management?

Accepted Answer

To maintain consistent yarn tension by continuously monitoring actual tension and making real-time adjustments.

Answer

To manually adjust yarn tension at predetermined maintenance intervals.

Answer

To eliminate the necessity for let-off and take-up mechanisms.

Answer

To regulate yarn speed without measuring actual output tension feedback.

Question 2

In a weaving machine, which mechanism is specifically responsible for releasing warp yarns from the warp beam at a controlled rate?

Accepted Answer

Let-off mechanism

Answer

Take-up mechanism

Answer

Shedding mechanism

Answer

Reed mechanism

Question 3

What is the main function of the take-up mechanism in a weaving loom?

Accepted Answer

Withdrawing the cloth from the weaving area at a constant rate and winding it onto a cloth roller.

Answer

Propelling weft yarn through the shed.

Answer

Calculating proportional, integral, and derivative responses for nozzle control.

Answer

Releasing warp yarn from the warp beam.

Question 4

Which medium is utilized by air jet looms to propel the weft yarn through the shed at high insertion speeds?

Accepted Answer

High-pressure jets of air

Answer

Magnetic shuttles

Answer

Hydraulic fluid streams

Answer

Flexible rapier tapes

Question 5

What weaving speed can modern air jet looms achieve?

Accepted Answer

Over 1,200 picks per minute (ppm)

Answer

Up to 300 picks per minute (ppm)

Answer

Exactly 500 picks per minute (ppm)

Answer

Over 5,000 picks per minute (ppm)

Question 6

Which set of issues is directly caused by excessive yarn tension during weaving?

Accepted Answer

Increased yarn breakage, reduced fabric elasticity, and yarn structure damage

Answer

Complete elimination of warp breaks and slubs

Answer

Lower weaving speeds and higher yarn thickness

Answer

Increased fabric elasticity and reduced yarn breakage

Question 7

Which electronic component in modern air jet looms coordinates nozzle firing times, warp tension, and weave patterns?

Accepted Answer

Programmable Logic Controllers (PLCs)

Answer

Mechanical drop wires

Answer

Manual tension bands

Answer

Friction discs

Question 8

What maximum weft insertion rate can modern air jet looms achieve?

Accepted Answer

Up to 2,200 meters of pick inserted per minute

Answer

Up to 500 meters of pick inserted per minute

Answer

Up to 120 meters of pick inserted per minute

Answer

Up to 10,000 meters of pick inserted per minute

Question 9

Which raw yarn quality defects are common causes of warp yarn breakage during weaving?

Accepted Answer

Weak spots, slubs, knots, and inconsistent thickness

Answer

Excessive yarn count uniformity

Answer

High elasticity and optimal friction coefficient

Answer

Uniform diameter and consistent yarn tenacity

Question 10

Why is accurate calibration of loom components, such as nozzles and tensioning devices, vital in weaving?

Accepted Answer

It ensures consistent yarn insertion and high fabric quality.

Answer

It removes the need for Electronic Control Units (ECUs).

Answer

It exponentially increases yarn friction around cylinders.

Answer

It enables open-loop operation without feedback monitoring.
