Water Displacement Method: Measure Irregular Object Volume

Fill a graduated cylinder with water and record the initial volume. Gently submerge the irregular object. Record the new water level. The object's volume equals the final water level minus the initial water level.

Easy ⏱ 15-20 min 🔭 Class 6-8 🏠 Everything is already at home

Time: 15-20 min
Difficulty: Easy
Best for: Class 6-8
Subject: Physics
Things needed: 5, all at home
Steps: 12
Cost: Free, nothing to buy
You will learn: Water Displacement and Density

Water Displacement Method: Measure Irregular Object Volume, Experiment · 6-8 | jijnas.com

Before you start

What you need

0 of 5 ready

Tap each thing once you have it in front of you. Items with the house sign are already somewhere in your home.

🏠 Graduated cylinder (100 ml) or kitchen measuring cup with ml markings 1 piece No luck? Use clear narrow plastic bottle marked using a measuring syringe or cup.
🏠 Small irregular object (stone, metal bolt, or brass key) 1-2 pieces
🏠 Cotton thread or thin string 30 cm
🏠 Water 200 ml
🏠 Blue fountain pen ink or liquid Ujala (optional, for clear reading) 2 drops No luck? Use food coloring.

💬 Send to a parent

Think first

What do you think will happen?

Real scientists guess before they look. Write one line now. After the steps, the page will show it next to what you should see.

Do it

The procedure

Tap a step when it is done. Lab mode shows one step at a time in big letters, reads it aloud if you want, and keeps the timer.

Fill your graduated cylinder roughly halfway with water.
Add two drops of blue ink or food coloring to help you see the liquid line clearly.
Set the cylinder down on a flat, stable tabletop.
Lower your head until your eyes are horizontally level with the water surface.
Record the scale reading at the lowest point of the curved water surface as your initial volume (V1).
Tie a piece of thin cotton thread securely around the irregular object.
Lower the object slowly into the liquid using the thread to prevent any splashing.Splashing liquid out of the container will ruin the accuracy of your measurement.
Tap the side of the cylinder lightly to free any trapped air bubbles from the object.Bubbles attached to the object displace extra water and will give an falsely high volume.
Verify that the object is entirely under water and not resting above the surface.Partial submersion leads to an incorrectly low reading.
Position your eye level with the elevated water line.
Record the measurement at the bottom of the new curved line as your final volume (V2).
Subtract V1 from V2 to determine the exact volume of your object in milliliters.

01 · The idea

The Concept

Measuring regular shapes like cubes or spheres relies on geometric formulas, but irregular shapes like rocks require liquid displacement to accurately determine 3D space.

02 · What you should see

Observation

When you submerge an irregular object, like a small stone, into a cylinder partially filled with water, you will see the water level instantly rise. If you start with 50 mL of water and the level goes up to 65 mL after dropping the object in, the water has shifted upward. No extra liquid was added from the outside, the object simply pushed the water up to make room for itself.

03 · Why it happens

Why It Happens

Two physical items cannot occupy the exact same space at the exact same time. When the stone enters the water, it needs space for itself, so it pushes a matching volume of water out of its path. Because the sides of the cylinder prevent the liquid from moving sideways, the displaced water has nowhere to go but up.

Think of it like stepping into a full bathtub. When you sit down in the tub, the water level rises and might even spill over because your body takes up space that the water was holding just a moment before.

04 · The science

The Science Behind It

This technique relies on Archimedes' principle, which explains that an object placed in a fluid pushes aside a volume of fluid equal to its own total volume. While regular items like a wooden block can be measured using length, width, and height formulas, irregular items do not have flat edges or uniform shapes.

In your science measurement lessons, you learn that volume represents the three-dimensional space an object occupies. Because liquid water cannot be easily compressed, it is forced upward when a solid enters. Since 1 milliliter (mL) of water occupies exactly 1 cubic centimeter (cm³) of space, calculating the displaced water in milliliters gives you the exact volume of the irregular object in cubic centimeters.

05 · Take it further

Make It a Project

Test different irregular items like metal bolts, plastic toys, or glass marbles to compare their displaced volumes. Keep the initial water volume, water temperature, and eye-level meniscus reading consistent across all trials. You can present your findings by displaying side-by-side photo comparisons showing how to read the bottom of the meniscus to avoid parallax error.

06 · Questions students ask

FAQs

What happens if the irregular object floats in the water?

If your object floats, it will not displace its full volume. You can gently push it just below the surface using a thin needle or string. Alternatively, attach a heavy sinker with a known volume, submerge both, and subtract the sinker's volume from the total.

Why is water displacement better than using a ruler for irregular objects?

A ruler works well for rectangular blocks because you can easily multiply length, width, and height. Irregular objects like rocks or keys have uneven curves and edges that you cannot measure accurately with a ruler. Water fills every contour, giving an exact volume.

How do you avoid parallax error when reading the water level?

Place your graduated cylinder on a flat table and bring your eyes directly level with the surface of the water. Water curves slightly at the edges, forming a shape called a meniscus. Always read the measurement from the very bottom of this curved line.

Is 1 milliliter of displaced water equal to 1 cubic centimeter?

Yes, 1 milliliter (mL) is exactly equal to 1 cubic centimeter (cm³). When you measure the displaced water in milliliters using a graduated cylinder, you can instantly record your solid object's volume in cubic centimeters without needing any extra unit conversions.

Can you use water displacement to measure water-soluble objects?

No, you should not use water for objects like sugar cubes or salt crystals because they dissolve in water. To measure soluble objects using displacement, you must use a non-water liquid that does not dissolve the object, such as vegetable oil or rubbing alcohol.
